HK360S

HK360S

Jiye mini skid steer loader is a compact workhorse designed for tight spaces and varied job sites. It replaces manual labor in areas where larger machines can't go, making it ideal for landscaping, farming, construction, and municipal maintenance.

Key Features


Compact & Agile

The narrow machine width allows easy access through standard doorways, narrow alleys, and basement entrances, perfect for both indoor and outdoor confined spaces.


Multi-Purpose

With a quick coupler system, one machine handles digging, loading, forking, sweeping, snow clearing, drilling, and more. Attachment changes are fast and tool-free.


Easy to Operate

Clear controls and good visibility make it beginner-friendly. Options include walk-behind, remote control, or traditional joysticks to fit different user preferences.


Simple Maintenance

The engine hood tilts open for full access. Filters and hydraulic hoses are clearly routed, making daily checks and service quick and easy.


Durable & Reliable

Key components are from proven brands. The reinforced structure supports long-hour continuous operation.


Typical Applications

Landscaping: soil moving, tree ball transport, paving

Farming: manure cleaning, feed handling, material

Construction: material, debris clearing, narrow trenching

Municipal: snow removal, leaf small repair jobs


Support & Warranty

We offer machine warranty and long-term spare parts support. Every unit is tested before shipment, and a test video is provided. Common wear parts are traceable and consistently available for years to come.


Product Specifications


Engine OptionsRatORFD40DHeight to Bucket Pin2000mmTravel Speed0-4.8km/hMax Ground Clearance420mm

Rated Power

18kWHeight to Bucket Edge1690mmMax Load Capacity300kgMax Bucket Rock Angle115°
Standard Speed3600rpmMax Height with Bucket Level1810mmMax Breakout Force3500NMax Bucket Rollback Angle90°
Cylinders2Length without Attached Bucket2500mmMax Breakout Force350kNBucket Volume0.06m³
AspirationNaturalLength with Standard Bucket2870mmTravel Speed0-6km/hOperating Weight1030kg
EmissionTier 4Max Dump Angle39°Three-cycle time9s

Fuel Tank22LMax Dump Height1250mmSystem Pressure17-21bar

Fuel Tank Capacity18LMax Operating Height2420mm
