| Project | Parameter Details |
| Model | JY17 |
| Weight | 1200kg |
| Dimensions (LWH) | 255011502200mm |
| Engine Options | （Kubota）D722 /（Laidong）3B2 /（Kubota）D902 |
| Engine Power | 10.2KW/29KW/11.8KW |
| Engine Speed | 2500rpm/2350rpm/2300rpm |
| Fuel Consumption | 2-3 L/h |
| Gradeability | 30° |
| Control System | Pilot Control System |
| Hydraulic Tank | 14L |
| Fuel Tank | 9L |
| Oil Capacity | Oil level at 5th mark on dipstick |
| Max Digging Depth | 1900mm |
| Max Digging Height | 2560mm |
| Max Digging Radius | 3200mm |
| Min Swing Radius | 1600mm |
| Dozer Lift Height | 120mm |
| Dozer Lowering Depth | 230mm |
